NON-SERVER CONTROLLER
/* // SERVERLESS CONTROL FOR APPLIANCES // */
// *********************** CODE BEGIN ************************//
#include <ESP8266WiFi.h>
const char WiFiPassword[] = "USER_NODE";
const char AP_NameChar[] = "helloworld" ;
WiFiServer server(80);
String header = "HTTP/1.1 200 OK\r\nContent-Type: text/html\r\n\r\n";
String html_1 = "<!DOCTYPE html><html><head><title>LED Control</title></head><body><div id='main'><h2>LED Control</h2>";
String html_2 = "<form id='F1' action='LEDON'><input class='button' type='submit' value='LED ON' ></form><br>";
String html_3 = "<form id='F2' action='LEDOFF'><input class='button' type='submit' value='LED OFF' ></form><br>";
String html_4 = "</div></body></html>";
String request = "";
int LED_Pin = D0;
void setup()
{
pinMode(LED_Pin, OUTPUT);
boolean conn = WiFi.softAP(AP_NameChar, WiFiPassword);
server.begin();
} // void setup()
void loop()
{
// Check if a client has connected
WiFiClient client = server.available();
if (!client) { return; }
// Read the first line of the request
request = client.readStringUntil('\r');
if ( request.indexOf("LEDON") > 0 ) { digitalWrite(LED_Pin, LOW); }
else if ( request.indexOf("LEDOFF") > 0 ) { digitalWrite(LED_Pin, HIGH); }
client.flush();
client.print( header );
client.print( html_1 );
client.print( html_2 );
client.print( html_3 );
client.print( html_4);
delay(5);
// The client will actually be disconnected when the function returns and 'client' object is detroyed
} // void loop()
// ************************ CODE END **********************************//
